產品名稱：
LW8116-41RMY
產品簡介：
適用場所：辦公室門 財務室門 家庭房門 藥品庫門 政府機要室門 總經理辦公室門 智能小區
產品材質：鋅合金材料，標準密度6.75g/cm3
可選顏色：青古銅 紅古銅 金色 銀色 鍍真金
門厚要求：適合安裝在38mm-1000mm厚的門上
開門方式：密碼，卡片或機械鑰匙
驅動方式：電機雙向驅動
密碼容量：50個
卡片容量：200張
工作溫度：-20℃— +55℃
工作濕度：10%-90%.
抗靜電：>15000V
工作電壓：直流6V（4節堿性AA電池）
靜態功耗：小于40uA
動態功耗：小于200mA
電池壽命：正常連續開啟10000次左右
欠壓指示：當工作電壓低于4.8V左右時，開門會有弱電提示，此時還能開門200次左右
機械鎖體：天地桿防盜鎖體/五鎖舌三聯動鎖體，防插斜舌設計
電路板芯片： 荷蘭Philips 的 Mifare One 原裝進口芯片
適用卡型：Mafire 1卡
產品尺寸：350*90mm
Product features
Application places: office door, accounting office door, family door, drug depository door, government confidential room door, general manager's office door, intelligent village
Product material: zinc alloy material, standard density 6.75 g/cm 3
Optional color: green bronze， red bronze，gold ,silver ,gilt
Door thick requirement: suitable for installation in 38 mm - 1000 mm thick door
Open the door way: password, card or mechanical keys
Driving mode: motor two-way drive
Password capacity: 50
Card capacity: 200 copies
Working temperature: - 20 ℃ - + 55 ℃
Work humidity: 10% -90%.
Antistatic: > 15000 v
Working voltage: dc 6 V (section 4 basic AA battery)
Static power: less than 40 uA
Dynamic power consumption: less than 200 mA
Battery life: normal continuous open 10000 times or so
Undervoltage instructions: when work voltage is lower than 4.8 V around, open the door there will be weak current hint, now still can open the door 200 times or so Mechanical lock body: heaven and earth bar anti-theft lock body/five lock tongue three linkage lock body, prevent plug oblique tongue design
Circuit chip: Dutch Philips Mifare One of original installation import chip
Applicable card type: Mafire 1 card
Product size:350 * 90mm
